首頁 > Home > Application Notes > QSFP-40G-CSR To View Optical Module Information On H3C S6850-56HF SwitchQSFP-40G-CSR To View Optical Module Information On H3C S6850-56HF Switch
Time: 2024-07-10
H3C has a QSFP-40G-CSR optical module, model number is QSFP-40G-CSR-MM850, which can be used normally on H3C S6850-56HF switch. Today, we would like to introduce you the way to view the information of this model optical module on H3C S6850-56HF switch.
Figure 1 H3C QSFP-40G-CSR-MM850 Optical Module
1. Link status of H3C QSFP-40G-CSR-MM850 optical module on H3C S6850-56HF switch.
Enter the command "display interface HundredGigE 1/0/29" to view the link information of the switch port (port number: 1/0/29) into which the optical module is inserted, mainly including the link status of the optical module inserted in the port, the working rate, and so on.
2. Identification information of H3C QSFP-40G-CSR-MM850 optical module on H3C S6850-56HF switch.
Enter the command "display transceiver interface HundredGigE 1/0/29" to view the identification information on the switch port (port number: 1/0/29) into which the optical module is inserted, mainly including: the H3C model of the optical module inserted in the port, the type of fiber connector, the transmission distance, the operating wavelength, and the connection status. The main information includes: H3C model of the optical module inserted in the port, fiber connector type, transmission distance, working wavelength, etc.
3. DOM information of H3C QSFP-40G-CSR-MM850 optical module on H3C S6850-56HF switch.
Enter the command "display transceiver diagnosis interface HundredGigE 1/0/29" to view the DOM information on the switch port (port number: 1/0/29) where the optical module is plugged in, which mainly includes: temperature, voltage, bias current, transmitter current, and transmitter current when the module is working. The DOM real-time values of the module's operating temperature, voltage, bias current, transmit optical power, receive optical power, and so on.
Moduletek can provide compatible H3C QSFP-40G-CSR-MM850 optical module products.
If you have any questions about the above content, please contact us via email: sales@moduletek.com
